Perfect Combination of Practical Technology Optical LED street Light
Model Number : EK-LDC16
Назва продукту: Світлодіодний вуличний ліхтар
Рекомендована потужність: 50 Вт 100 Вт 150 Вт 200 Вт
Waterproof Index : IP66
Індекс сейсмостійкості: IK08 IK09
Working Temperature(℃): -20-50
Surface Color : RAL9007 (available on request)
Contain Accessories : Complete finished street lights
Application Scenario
- Streets,Paths and bike lanes
- Residential Street
- Shared area, commercial
- Urban streets
- Rural roads,urban roads
- Freeways and cicular raods
Technical Norm
General highlights
- Used for any outdoor lighting places such as roads, squares
- Working temperature: -30 。 C/+50 。 c
- Adopting buckle design for easy installation and maintenanceLumen
- Using high-quality chips
- Less light decay, long-lasting and durable
- Lamp poles with different calibers
- Excellent heat dissipation
Optical properties
- Different lens arrangements in different areas and installation
- Uniform light distribution
- Modular design of light source for easy replacement
- output(absolute metering): 100o0lm-400oolm
- Color temperature: 2200K-6500K
- Color rendering index:>70
Shell and Finis
- Corrosion resistant die cast aluminum casing Cancer-A Cancer-B
- Electrostatic powder coating
- Protection level: IP66
- Impact protection: IK09
Technical Parameter
Technical Parameter | ||||
Model | EK-LDC16-50W | EK-LDC16-100W | EK-LDC16-150W | EK-LDC16-200W |
потужність | 50 Вт | 100W | 150W | 200W |
Input Voltage | AC100-277V | |||
Frequency Range | 50Hz/60Hz | |||
Power Factor | >0.95 | |||
Whole Lighting Effect | 180lm/w | |||
LED Lifespan | 50000H | |||
Rendering Index | CRI70 | |||
Color Temperature | 2200K-6500K | |||
IP | IP66 | |||
IK | IK09 | |||
Operation Temperature | minus 30+50℃ | |||
Storage Temperature | minus 20+60℃ 10%-90%RH | |||
Матеріал лінзи | PC LENS | |||
Installation Height | 6-8mm | 6-8mm | 8-10mm | 10-12mm |
